Mise en service
At power up, select
preferred laguage.
Select language
[1] English
Setup 1
Status
Menu
Com.
On
Warn.
Alarm
5
5
Hand
On
Power Up Screen
The Wizard start screen appears.
Press OK to start Wizard
Press Back to skip it
Setup 1
Status
Menu
Com.
On
Warn.
Alarm
Hand
On
Wizard Screen
if
0.0 Hz
0.0 kW
Setup 1
Status
Menu
Com.
On
Warn.
Alarm
Hand
On
Status Screen
The Wizard can always be
reentered via the Quick Menu!
Wizard completed
Press OK to accept
Setup 1
0.0 Hz
0.0 kW
Setup 1
Illustration 5.6 Assistant de démarrage pour les applications en boucle ouverte
28
Manuel d'utilisation
Main
Quick
Menu
Menu
OK
O
Auto
Reset
On
OK
if
OK
Quick
Main
Menu
Menu
OK
O
Auto
Reset
On
Quick
Main
Menu
Menu
OK
O
Auto
Reset
On
(Do not perform AMA)
Auto Motor Adapt OK
Press OK
Setup 1
Danfoss A/S © Rév. 06/2014 Tous droits réservés.
... the FCP106 /FCM106 Wizard starts
0-03 Regional Settings
[0]
International
Setup 1
Grid Type
0-06
[12]
380-440V/50Hz
Setup 1
1-10 Motor Type
Asynchronous
[0]
PM motor
Setup 1
1-24 Motor current
3.8
A
Setup 1
1-25 Motor nominal speed
3000
RPM
Setup 1
1-26 Motor Cont. Rated Torque
5.4
Nm
Setup 1
1-30 Stator resistance
0.65
Ohms
Setup 1
1-39 Motor poles
8
Setup 1
1-40 Back EMF at 1000 rpm
57
V
Setup 1
1-37 d-axis inductance
5
mH
Setup 1
4-19 Max Output Frequency
0065
Hz
Setup 1
4-12 Motor Speed low Limit
0000
Hz
Setup 1
4-14 Motor Speed high Limit
0050
Hz
Setup 1
3-41 Ramp 1 ramp-up time
0003
s
Setup 1
3-42 Ramp 1 ramp-down Time
0003
s
Setup 1
Motor Type = PM Motor
6 - 19 T53 Mode
Current
[0]
Current
Setup 1
6 - 12 T53 Low Current
04.66
A
Setup 1
6 - 13 T53 High Current
13.30
A
Setup 1
3-02 Min Reference
0000
Hz
Setup 1
3-03 Max Reference
0050
Hz
Setup 1
5 - 40 Function of Relay 1
[0]
[0] No function
Setup 1
5 - 40 Function of Relay 2
[1]
No function
Setup 1
1-29 Automatic Motor Adaption
[0]
O
Setup 1
AMA running
-----
Setup 1
AMA OK
Asynchronous Motor
1-20 Motor Power
kW
1.50
Setup 1
1-22 Motor Voltage
0050
V
Setup 1
1-23 Motor frequency
0050
Hz
Setup 1
1-24 Motor current
04.66
A
Setup 1
1-25 Motor nominal speed
1420
RPM
Setup 1
Motor Type = Asynchronous
1-73 Active Flying start?
[0]
Disable
Setup 1
Voltage
6 - 10 T53 low Voltage
0050
V
Setup 1
6 - 11 T53 high Voltage
0220
V
Setup 1
Perform AMA
AMA Failed
AMA failed
MG03L204
