Fox 32TC Taper-Cast Instructions D'installation page 5

7. Install the brakes according to the brake manufacturer's instructions.
Maximum rotor size is 180 mm.
The disc brake caliper mounting bolts must have 10-12 mm of
thread engagement with the fork. Use a torque wrench to tighten
the caliper mounting bolts to the disc brake manufacturer's
specification, but do not exceed 10.2 N•m (90 in-lb). Improper
installation can lead to brake failure, resulting in a loss of control
of the bicycle and SEVERE INJURY OR DEATH.
8. Route the front disc brake hose or cable housing to the inside of the
lower leg, and through the supplied disc brake housing guide. Use a
torque wrench to tighten the disc brake hose guide screw to
0.9 N•m (8 in-lb).
KABOLT INSTALLATION
1. Install the front wheel into the fork dropouts. Slide the
12 x 100 mm Kabolt axle through the non-drive side
dropout and hub.
2. Use a 5 mm hex wrench to torque the Kabolt axle
(clockwise) to the torque specification that is etched
on the head of the Kabolt.
Over-tightening or under-tightening the axle can damage the axle or fork dropouts, leading to a
sudden failure with one or more of these components, resulting in SEVERE INJURY OR DEATH.
Failure to secure the axle properly can cause the wheel to become detached from the bicycle,
resulting in SEVERE INJURY OR DEATH.
WARNING
WARNING
5
10-12 mm thread
engagement
