9.6.2 Use of 1.5X additional lens (ST-086.1)
1.5X additional lens has a Working Distance of 47 mm and, in
case of very thin specimens (when working with SLX-2 / SLX-3
models), the microscope cannot get a proper focus.
In order to overcome this effect, the 1.5X lens is provided with
a transparent spacer ④ that must be placed on the base plate
(Fig. 26).
Once placed the transparent spacer, the user can put the speci-
men on the spacer and begin the observation as usual.
9.7 Use of illumination
1. Turn the transmitted light knob ⑤ in order to turn ON/OFF or
to change the intensity of the transmitted light LED. (Fig. 27)
2. Turn the incident light knob ⑥ in order to turn ON/OFF or to
change the intensity of the incident light LED.
• It is possible to use both illuminations at the same time.
9.8 Use with rechargeable batteries
When the power supply is connected to the microscope socket,
the "CHG" led ⑦ is lit. (Fig. 28)
RED light: battery with low charge or recharging
GREEN light: battery charged.
• NOTE: when the power supply is disconnected, the CHG led
is always off.
9.9 Use of eye shields
• Use with eyeglasses
Fold rubber eyeshields with both hands. Folded eyeshields avoid
scratching the lenses of eyeglasses. (Fig. 29)
