Thank you, and congratulations on your choice of the Roland MICRO CUBE BASS RX Amplifier.
Before using this unit, carefully read the sections entitled: "USING THE UNIT SAFELY" and "IMPORTANT NOTES" (p. 2; p. 4).
These sections provide important information concerning the proper operation of the unit. Additionally, in order to feel assured that you have gained
a good grasp of every feature provided by your new unit, Owner's manual should be read in its entirety. The manual should be saved and kept on hand
as a convenient reference.
Main Features
A compact, high-performance bass amplifier ideal for practising at home
Equipped with four newly developed 10-cm (4-inch) speakers, this compact but powerful 5-watt stereo power amp (2.5 watt + 2.5 watt) delivers a clear
bass sound.
Dual power operation with alkaline batteries (6 x AA) or AC adaptor (p. 5)
Dual power operation allows the amplifier to be used anywhere.
Wide range of tone variation provided by eight different COSM amp types (p. 6)
Adds the original amps SUPER FLAT and OCTAVE BASS to the standard 5-type bass amp modeling. Combined with the three-band equalizer, enables
finely textured sound creation. Can also be used as a simple PA system using the MIC.
COSM (Composite Object Sound Modeling) is proprietary Roland modeling technology, which analyzes the way in which sound is affected by
elements such as electronic circuitry, structure, and materials, and combines these elements to reconstruct the desired sound.
Three internal effect systems (six types) optimized for bass (p. 7)
In addition to the COMPRESSOR indispensable for bass sound, the amp is also equipped with an EFX system (CHORUS, FLANGER, and T-WAH)
and DELAY/REVERB.
RHYTHM GUIDE function makes practical rhythm training easy (p. 9)
Contains preset rhythms from 11 genres (33 patterns) such as ROCK, JAZZ, LATIN and METRONOME. The optional footswitch allows you to operate
the START/STOP and TAP TEMPO controls with your feet while playing.
Tuner function supports six-string bass tunings (p. 9)
The amp is equipped with a bass tuner function that supports six-string bass tunings.
AUX IN allows stereo playback (p. 8)
You can connect a CD/MP3 player to the AUX IN jack and play the music in stereo.
Stereo headphone output supported (p. 8)
The amplifier has a stereo PHONES jack that can also be used as a REC OUT jack.
No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION.
Owner's Manual
Copyright © 2008 ROLAND CORPORATION All rights reserved.
