Foot support
For use of back standing:
When the knee support is turned, the foot
supports must be mounted in the same side as
they were demounted.
1. Mount the foot supports and tighten the
2. Loosen the screw (B) and adjust the depth
3. Loosen the screws (C) and (D) and turn the
C
4. Tighten the screws in the requested
The foot plate mounting is mounted on the joint.
By means of this, the footplate can be adjusted
in different angles by loosening the screws (C)
og (D).
The plate can be adjusted in the depth by
loosening the handle (E), or the unbracho screw
(B).
E
handle. (A).
of the foot support.
foot support 180°.
position.
