2 Specifications
Item
Name
Model
Product
Length × Width × Height
Folded: Length × Width × Height
Net Weight
Payload
Rider Recommended Age
Required Height
Max. Speed
Typical Range [1]
Max. Slope
Traversable Terrain
Machine
Operating Temperature
Storage Temperature
IP Rating
Duration of Charging
Nominal Voltage
Max. Charging Voltage
Charging Ambient Temperature
Battery
Nominal Capacity
Nominal Energy
Battery Management System
Motors Nominal Power
Output Power
Input Voltage
Charger
Max. Output Voltage
Rated Output
Brake Light
Features
Speed Mode
Tire Pressure
Tire
Tires
[1]: Typical Range: tested while riding with a full battery, 165 lbs (75 kg) load, 77°F (25°C), at the speed of 16 km/h on average on pavement. * Some of
the factors that affect range include speed, number of starts and stops, ambient temperature, etc.
03
Parameter
Ninebot KickScooter
D38U
Approx. 45 × 18.9 × 45.7 in (1143 × 480 × 1160 mm)
Approx. 45 × 18.9 × 19.5 in (1143 × 480 × 495 mm)
Approx. 36.2 lbs (16.4 kg)
66–265 lbs (30–120 kg)
14–60 years
3'11''–6'6'' (120–200 cm)
Approx. 18.6 mph (30 km/h)
Approx. 23.6 miles (38 km)
Approx. 20%
Asphalt/flat pavement; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm)
14–104°F (-10–40°C)
14–122°F (-10–50°C)
IPX5
Approx. 6.5 h
36 V
42 V
32–104°F (0–40°C)
10.2 Ah
367 Wh
Over-heating, short circuit, over-current, over-discharge and
over-charge protection
350 W
70 W
100–240 V~
42 V
41 V 1.7 A
LED Rear Light
Energy-saving mode, Standard mode and Sport mode
40–45 psi
10-inch pneumatic tires
3
Certifications
This product is certified to ANSI/CAN/UL-2272 by TUV Rheinland.
The battery complies with UN/DOT 38.3.
The battery complies with ANSI/CAN/UL-2271.
Federal Communications Commission (FCC) Compliance Statement for USA
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
Cet équipement est conforme aux limites d'exposition aux radiations de la IC définies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps.
Industry Canada (IC) Compliance Statement for Canada
This device complies with Industry Canada license-exempt RSS standard (s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
CAN ICES-3 (B)/NMB-3(B)
"Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement."
Neither Segway Inc. nor Ninebot is responsible for any changes or modifications not expressly approved by Segway Inc.
or Ninebot. Such modifications could void the user's authority to operate the equipment.
FCC ID: 2ALS8-KS0005
IC: 22636-KS0005
