Deleting programmed outdoor switches from the handheld transmitter
• Press the ON and OFF buttons simultaneously, for the switching channel to which the remote controlled
outdoor switch is programmed. The LED (6) starts blinking.
• Now, press the "ALL-ON" (3) button and the "ALL-OFF" (4) button simultaneously. The LED (6) will go out.
All remote controlled outdoor switches have been successfully deleted from the handheld transmitter.
To delete one single receiver, press the corresponding OFF button for the switching
channel, to which the receiver was programmed, instead of pressing the "ALL-ON" (3)
and "ALL-OFF" (4) buttons.
The Handheld Transmitter's Dimmer Function
Turn the dimmer on, by briefly pressing the ON button for the corresponding switching channel.
Press and hold down the ON key for the corresponding switching channel. The dimmer function is activated.
Press the ON key for the corresponding switching channel again. The dimmer function is deactivated.
This function is only available for radio receivers with integrated dimmer.
Start-up, Function Test
Set the correct switching group on the handheld transmitter, using the "Selector switch for switching group"
(2).
Plug the remote controlled socket (without the consumer load connected!) into the designated earthed mains
socket.
You can now test the function of the remote controlled outdoor switch, by briefly pressing the respective "ON"
button for the corresponding switching channel (1, 2, 3 or 4). The red LED (6) on the outdoor switch lights
up. The socket (7) on the front is now activated; the mains voltage is available and a connected consumer
load is turned on.
Briefly press the "OFF" button, for the switching channel, and the LED (6) goes out again; the mains voltage
to the front socket (7), and thus the connected consumer load, is turned off.
Operation
Connect the consumer load to the front socket (7).
Please consult the section "Technical Data" for the consumer load's permissible maxi-
mum power.
By using the respective "ON" or "OFF" button for the switching channel on the handheld transmitter, the
remote controlled outdoor switch is turned on/off for the same switching channel as set (the LED (6) lights
up or turns off).
Maintenance and Care
The product does not require any maintenance and should never be opened or disassembled for any reason.
Remove connected consumer loads from the remote controlled outdoor switch and remove it from the mains
socket, before cleaning the product.
Only clean the product with a soft, clean, dry cloth. Never use aggressive cleaning agents or chemical solu-
tions since these might damage the surface of the casing or impair the operation.
Handling
• The handheld transmitter must not get damp or wet. The remote controlled outdoor switch
enclosed is suitable for outdoor use (IP44).
• The following unfavourable conditions should be avoided at the installation site and during
transport:
- Moisture and humidity
- Direct sunlight
- Extreme cold or heat
- Dust or flammable gases, fumes or solvents
- Strong vibrations
- Strong magnetic fields such as those found in the vicinity of machinery or loudspeakers
• Ensure that the insulation for the entire product is neither damaged nor destroyed. Never
disassemble the product! There are no serviceable parts inside.
• Check the product for damage before each use!
If you notice any damage, do not use the product any longer!
There is a risk of a life-threatening electric shock!
Safe operation must be presumed to be no longer possible:
- if the device is visibly damaged
- if the device no longer works
- if the device was stored under unfavourable conditions for a long period of time
- if it was exposed to extraordinary stress caused by transport
Transmission range
The transmission range of the radio signals, between the handheld transmitter and the outdoor switch, is up
to 70 m under optimum conditions.
This value, however, is the so-called "open space range" (the range the transmitter and
receiver are visible to each other, without disturbing influences).
In practical operation, however, there are walls, ceilings of rooms etc. between the trans-
mitter and the receiver, which reduce the range accordingly.
Due to the different influences on the radio transmission, no specific range can be guaran-
teed.
However, trouble-free operation is usually possible in a detached house.
All manuals and user guides at all-guides.com
The range can sometimes be limited considerably by:
• Walls, reinforced concrete ceilings
• Coated/metallised insulated glass
• Proximity to metal & conducting objects (e.g., radiators)
• Proximity to human bodies
• Broadband interferences, e.g. in residential areas (DECT telephones, mobile phones, radio-controlled
• Proximity to electric motors, transformers, power-supply units, computers
• Proximity to badly shielded or uncovered computers in use or other electrical appliances
Disposal
a) In general
b) Batteries and Rechargeable Batteries
As the end user, you are required by law (Battery Ordinance) to return all used batteries/rechargeable bat-
teries; disposal of them in the household waste is prohibited!
Used batteries, rechargeable batteries as well as coin cells can be returned to collection points in your
municipality, our stores or wherever batteries/rechargeable batteries/coin cells are sold!
You thus fulfil the legal requirements and make your contribution to protecting the environment!
Declaration of Conformity (DOC)
We, Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declare that this product
conforms to the fundamental requirements and the other relevant regulations of the directive 1999/5/EC.
Technical Data
a) Handheld transmitter
Transmission frequency...............433 MHz
Power supply ...............................1x 12 V battery, type "23 A"
Range ..........................................Up to 70 m (open space, see chapter "Range")
LED ..............................................Lights up briefly, when the buttons are used
Switching groups .........................4
Programmable receivers or
number of switching channels .....16
Operating temperature range ......0 °C to +35 °C
Dimensions (L x W x H) ...............approx. 105 x 43 x 22 mm
b) Remote controlled socket
Reception frequency ....................433 MHz
Operating voltage ........................230 V/AC, 50 Hz
Protection class ...........................I
Connected power ........................max. 2000 Watts resistive load (internal thermal fuse)
Protection type .............................IP44
LED ..............................................Lights up, when the mains socket/consumer load is activated
Dimensions (L x W x H) ...............approx. 116 x 58 x 73 mm
You can program up to 10 transmitters for this remote controlled outdoor switch.
headphones, radio-controlled speakers, radio-controlled weather stations, baby phones etc.)
Dispose of an unserviceable product in accordance with the relevant statutory regulations.
Contaminated batteries/rechargeable batteries are labelled with these symbols to indicate that
disposal in the domestic waste is forbidden. The designations for the heavy metals involved are:
Cd = Cadmium, Hg = Mercury, Pb = Lead.
The Declaration of Conformity for this product can be found at www.conrad.com.
.........
This is a publication by Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau
(www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming,
or the capture in electronic data processing systems require the prior written approval by the editor.
Reprinting, also in part, is prohibited. This publication represent the technical status at the time of
printing.
© Copyright 2015 by Conrad Electronic SE.
