Memory Speed/CPU FSB Support Matrix
Memory
FSB
800 MHz
CPU Installation Procedures for Socket 754
1.
Please turn off the power and unplug the power cord before installing the CPU.
2.
Pull the lever sideways away from the socket. Make sure to raise the lever up to a
90-degree angle.
3.
Look for the gold arrow on the CPU. The CPU can only fit in the correct orientation. Lower
the CPU down onto the socket.
4.
If the CPU is correctly installed, the pins should be completely embedded into the socket
and can not be seen. Please note that any violation of the correct installation procedures
may cause permanent damages to your mainboard.
5.
Press the CPU down firmly into the socket and close the lever. As the CPU is likely to
move while the lever is being closed, always close the lever with your fingers pressing
tightly on top of the CPU to make sure the CPU is properly and completely embedded into
the socket.
Installing AMD Athlon64 CPU Cooler Set
When you are installing the CPU, make sure the CPU has a heat sink and a cooling fan attached
on the top to prevent overheating. If you do not have the heat sink and cooling fan, contact your
dealer to purchase and install them before turning on the computer.
1.
Detach the shield of the backplate's paster.
2.
Turn over the mainboard, and install the backplate to the proper position.
3.
Turn over the mainboard again and place the mainboard on the flat surface. Locate the
two screw holes of the mainboard.
4.
Align the retention mechanism and the backplate. Fix the retention mechanism and the
backplate with two screws.
5.
Position the cooling set onto the retention mechanism. Hook one end of the clip to hook
first.
DDR 266
DDR 333
OK
OK
DDR 400
OK
5
