Heat meter connection set

Technical description

3. Technical description
3.1

Design

3.1.1 Heat meter connection set in angle
version
4
3
2
1
Fig. 1: Design of the angle version
1 Ball valve for the return pipe with
temperature sensor connection
M10x1
2 Coupling
3 Heat meter spacer with hand-tight
fitted reducers
4 Elbow coupling
5 Cocon QDP differential pressure
regulator
6 Impulse tube
7 Set of flat seals
8 Elbow coupling
9 Ball valve for the supply pipe with
temperature sensor connection
M10x1
20
3.1.2
4
5
3
6
2
7
1
8
Fig. 2:
9
1 Ball valve for the return pipe with
temperature sensor connection
M10x1
2 Coupling
3 Heat meter spacer with hand-tight
fitted reducers
4 Coupling
5 Cocon QDP differential pressure
regulator
6 Impulse tube
7 Set of flat seals
8 Coupling
9 Ball valve for the supply pipe with
temperature sensor connection
M10x1
Heat meter connection set in straight
version
Design of the straight version
140488480-V01.10.2021
5
6
7
8
9
