WARNING:
When servicing, use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes, resulting in possible
serious injury.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which may result in serious personal injury.
Electric tools used on fiberglass material, wallboard, spackling
compounds, or plaster are subject to accelerated wear and
possible premature failure because the fiberglass chips and
grindings are highly abrasive to bearings, brushes, commuta-
tors, etc. Consequently, we do not recommended using this
tool for extended work on these types of materials. However,
if you do work with any of these materials, it is extremely
important to clean the tool using compressed air.
Look for these accessories at the service center:
 Edge Guide .......................................................................................................................................................6090080-1
 25 pc. Carbide Router Bit Kit .............................................................................................................................A25RS25
 12 pc. Carbide Router Bit Kit .............................................................................................................................A25RS12
 8 pc. Starter Carbide Router Bit Kit ...................................................................................................................A25RS08
WARNING:
Current attachments and accessories available for use with this tool are listed above. Do not use any attachments or
accessories not recommended by the manufacturer of this tool. The use of attachments or accessories not recommended
can result in serious personal injury.
NOTE: FIGURES (ILLUSTRATIONS) START ON PAGE 13
AFTER FRENCH AND SPANISH LANGUAGE SECTIONS.

MAINTENANCE

ACCESSORIES

This product has a Three-year Limited Warranty.
For Warranty details go to www.ryobitools.com
LUBRICATION
All of the bearings in this tool are lubricated with a sufficient
amount of high grade lubricant for the life of the unit under
normal operating conditions. Therefore, no further lubrica-
tion is required.
POWER SUPPLY CORD REPLACEMENT
If replacement of the power supply cord is necessary, this
must be done by an authorized service center in order to
avoid a safety hazard.
CLEANING THE BITS
Get faster, more accurate cutting results by keeping
bits clean and sharp. Remove all accumulated pitch and
gum from bits after each use. When sharpening bits, sharpen
only the inside of the cutting edge. Never grind the outside
diameter. When sharpening the end of a bit, be sure to grind
the clearance angle the same as originally ground.
CLEANING THE COLLET
Dust and chips may collect on the collet from time to time,
making it necessary to clean the collet. To do so, remove
the collet assembly and wipe it with a clean, dry rag. Clean
the taper in the shaft in the same manner. Never immerse
the collet or end of the shaft in a solvent or in water. Before
replacing the collet assembly, put a drop of SAE30 motor oil
on the inside of the nut, on the treads of the shaft, and on
the taper in the shaft. Replace the collet assembly onto the
shaft by hand only. Never tighten the collet nut without a bit in
the collet. This action could permanently damage the collet.
12 − English
