9 BATCHING
1 To use the Batching memory facility, press the Batch softkey
2 Select "New Batch" or "Open Existing Batch" to add readings
3 Copy, Rename, Review batch data and Clear readings from or Delete a batch
4 Fixed Batch Size allows users to pre-define the number of readings to be stored in a batch.
Once all readings have been taken the gauge automatically opens a new batch with a link
to the original batch name. For Example NewBatch becomes NewBatch_1, NewBatch_2, etc.
4
Save each reading into memory or store the average of a pre-defined number of readings
using the Counted Average function
10 DISPLAYING GRAPHS
To display the trend graph of the last 20 readings (Model S & T):
1 Press the Batch softkey
2 Select "New Batch" or "Open Existing Batch"
3 Press the Stats softkey and select "Show Graph on LCD"
4
Red points signify a reading outside the batch's limits (if set)
To display the Batch Readings Graph (Model T):
1 Select the appropriate batch name from Batch/Review Batch
2 Select "Graph"
4
Red columns signify a reading outside the batch's limits (if set)
4
Press the Zoom softkey followed by ç
readings as required
9
or è to review individual
