maintenance

Drive recommends periodic visual inspection of this

product by the user, to ensure that all parts and hardware

are secure, that components are in good working order

and not worn, torn, frayed, or loose, and that there are no

obstructions or impediments to normal, safe operation.

If any part or mechanism appears to be unsafe or

compromised, do not use the product. If you experience

problems, please contact the provider that sold you the

product or visit www.drivemedical.com/help for more info.

lifetime limited warranty

Your Drive brand product is warranted to be free of defects

in materials and workmanship for the lifetime of the original

consumer purchaser.

This device was built to exacting standards and care fully

inspected prior to shipment. This Lifetime Limited Warranty

is an expression of our confidence in the materials and

workmanship of our products and our assurance to the

consumer of years of dependable service.

This warranty does not cover device failure due to own

er misuse or negligence, or normal wear and tear. The

warranty does not extend to nondurable components, such

as rubber accessories, casters, and grips, which are subject

to normal wear and need periodic replacement.

If you have a question about your Drive device or this

warranty, please contact an authorized Drive dealer.

WARNING: This product can expose you to chemicals,

including bisphenol A (BPA), which is known to the State

of California to cause birth defects or other reproduction

harm. For more information go to www.P65Warnings.ca.gov.

Drive is a trademark of Medical Depot, Inc.

Port Washington N.Y. 11050 USA Made in China

Travel Rollator

Andador de viaje

Déambulateur

de voyage

Item # RTL800KD-BK

EU Authorized Representative

Y Sung Handelscertretung

Duesselthaler St. 24, 40211

Duesseldorf, Germany

www.drivemedical.com

VER.A.3.21

Sommaire des Matières pour Drive RTL800KD-BK

Page 1 Item # RTL800KD-BK Your Drive brand product is warranted to be free of defects in materials and workmanship for the lifetime of the original consumer purchaser. This device was built to exacting standards and care fully inspected prior to shipment.
Page 2 assembly instructions assembly instructions 1. Remove all contents from packaging. 3. Attach back wheel assembly (with handbrakes) (C) using the same process as described in Step 2 making sure the wheels are positioned on the outside of the rollator. 4. Position rollator upright and insert the left handle tube into frame and set to desired height.
Page 3 Orthodic loop lock operation Hand Grips Loop Locks Always engage and disengage wheel locks on both sides simultaneously. Backrest 1. To Slow Down or Come to a Temporary Stop—Pull up slowly on Height the loop locks with four fingers until Comfortable Adjustment Knobs Padded Seat...
Page 4 instrucciones de armado instrucciones de armado 3. Conecte el conjunto de la rueda trasera (con frenos de 1. Retire todo el contenido del embalaje. mano) (C) utilizando el mismo proceso que se describe en el Paso 2, asegurándose de que las ruedas estén colocadas en la parte exterior del andador.
Page 5 Empuñaduras Sistema de Seguridad Con operación del freno curvo Ortopédicas Frenos Curvos Disponible Siempre engrane y desengrane los frenos de las ruedas en Respaldo ambos lados simultáneamente. Altura Adjustable 1. Para Disminuir la Marcha o Hacer una Asiento Detención Temporaria—Jale lentamente Acolchado Cómodo de los frenos curvos con cuatro dedos hasta que la unidad disminuya la marcha...
Page 6 montage montage 3. Fixez l’ensemble de roue arrière (avec freins à main) (C) en 1. Retirez tout le contenu de l’emballage. utilisant le même processus que celui décrit à l’étape 2 en vous assurant que les roues sont positionnées à l’extérieur du déambulateur.
Page 7 fonctionnement du verrouillage à boucle Poignées Verrouillage à Boucle Anatomiques Toujours verrouiller et déverrouiller les roues des deux côtés simultanément. Dossier 1. Pour ralentir ou s’arrêter – relevez légèrement sur la boucle de verrouillage Hauteur Ajustable avec vos quatre doigts jusqu’à ce Siège Rembourré...
Page 8 à vie, limitée garantía limitada de por vida Ce produit Drive est garanti d’être exempt de tout défaut de matériau, de fabrication ou de main d’oeuvre, auprès Su producto marca Drive está garantizado de por vida du propriétaire original et ce, pour la durée de la vie de...
