ROBINET A TOURNANT SPHERIQUE 2 PIECES A BRIDES
PN16 INOX DIN LONG (3202-1 F1) GAMME PERFORMANCE
NOMENCLATURE DN 65 - 100
Repère
10*
11*
12*
:
Désignation
1
Corps
2
Embout
3
Sphère
4
Ecrou
5
Goujon
6*
Joint de corps
7*
Sièges
8*
Bague
9*
Bague
Bague
Presse étoupe
Presse étoupe
13
Bague
14
Bague
15
Axe
16
Butée
17
Fouloir
18
Circlips
19
Vis
20
Adaptateur poignée
21
Poignée
22
Vis
Matériaux
ASTM A351 CF8M
(1.4408)
AISI 304
Graphite
PTFE
PTFE chargé 25% carbone
Graphite
PTFE chargé 25% carbone
AISI 304
AISI 316
AISI 304
1.4308
AISI 304
1.4308
AISI 304
REF.763L
( * : Compris dans le kit joints )
