ROBINET A TOURNANT SPHERIQUE 2 PIECES A BRIDES
PN16 INOX DIN LONG (3202-1 F1) GAMME PERFORMANCE
:
NOMENCLATURE DN 15 - 50
Repère
10*
Désignation
1
Corps
2
Embout
3
Sphère
4*
Sièges
5*
Joint de corps
6*
Bague
7*
Bague
8
Axe
9*
Presse étoupe
Presse étoupe
11
Fouloir
12
Rondelles élastiques
13
Ecrou
14
Rondelle frein
15
Butée
16
Vis butée
17
Poignée
18
Gaine poignée
19
Goujon
20
Ecrou
Matériaux
ASTM A351 CF8M
(1.4408)
PTFE
Graphite
PTFE chargé 25% carbone
PTFE chargé 25% carbone
ASTM A276-316
Graphite
PTFE chargé 25% carbone
AISI 304
AISI 301
AISI 304
PVC
AISI 304
REF.763L
( * : Compris dans le kit joints )
