Installation Steps

Use an alcohol pad to clean the hood surface that
aligns with the center flange of the hood shield.
3
holes in OUTBOARD
flange
5
Insert (2) screws and washers through the rubber gasket, hood shield, and into the hood, at the OUTBOARD flange
6
Remove remaining tape liner from the center flange
7
NOTE: Actual application may vary slightly from illustrations.
Center the hood shield on the hood.
Slide the OUTBOARD flanges between the hood and rubber seal and align with holes.
locations noted above. Securely tighten.
.
Peel back 2" of tape liner from one end of center flange to
create a tape tab. Ensure tab is accessible
4
DO NOT OVER TIGHTEN
Apply firm pressure to center flange to ensure adhesion of tape to
8
Page 2 of 3
.
holes in OUTBOARD
flange
hood shield
hood seal / gasket
washer
self tapping
screw
hood surface.
tape
tab
