 Selection of pipe materials and size
Selection of pipe material
Material: Phosphorus deoxidation seam-less pipe
Capacity code of indoor and outdoor units
• For the indoor unit, the capacity code is decided at each capacity rank.
• The outdoor unit's capacity codes are decided at each capacity rank.
The maximum No. of the connectable indoor unit and the total value of the indoor unit's capacity codes are also
decided.
Minimum wall thickness for R410A application
Soft Half Hard or Hard
OK OK
OK OK
OK OK
OK OK
NG *(1) OK
*(1) If the pipe size is Ø3/4" (19.05), use a suitable material.
Table 1
Capacity code
Indoor unit
Equivalent to
capacity type capacity type
capacity
007 type 7.5
009 type 9.5
012 type 12
015 type 15.4
018 type 18
021 type 21
024 type 24
027 type 27
030 type 30
Table 2
Capacity code
Outdoor unit capacity
type
Equivalent to capacity
036 type 36
048 type 48
060 type 60
*(2) In case of an Outside Air Unit connection , capacity code is only 48.
EN-17
OD (Inch) OD (mm) Minimum wall thickness (mm)
1/4" 6.35
3/8" 9.52
1/2" 12.70
5/8" 15.88
3/4" 19.05
Capacity code
Indoor unit
Equivalent to
capacity
036 type 36
042 type 42
048 type 48
— —
— —
— —
— —
— —
— —
Total capacity code of connectable indoor
No. of connectable
units
indoor units
Min.
2 to 6 18
2 to 8 24 *(2)
2 to 9 30
– 9 –
 Selection of refrigerant piping
Gas pipe
Main pipe
0.80
0.80
0.80
1.00
1.00
No. Piping parts
Outdoor unit

(1)
1st branching
section
Max.
48
64 *(2)
81
Branching section
(2) 
Branching section
Outdoor unit
Liquid pipe
1st branching Branching Branching
section pipe header
(4) (5)
(2)
(1)
(3)
(3)
Branching
pipe
(2)
Name Selection of pipe size
Size of main pipe
Outdoor unit capacity type
Main pipe 0367 type
0487 type
0607 type
Pipe size between branching sections
Total capacity codes of
indoor units at down stream
side
Equivalent to capacity
Branching
pipe Below 23
23 to below 61
61 or more
(3) (3)
Indoor
unit
Y-shaped
branching joint
(4)
(3)
(3) Indoor
unit
Remarks
Gas pipe Liquid pipe
Same as the outdoor
Ø5/8" Ø3/8" unit's connecting pipe
size.
Ø5/8" Ø3/8"
Ø3/4" Ø3/8"
Pipe size differs based
on the total capacity
Gas pipe Liquid pipe
code value of the indoor
units at the downstream
side. If the total value
Ø1/2" Ø3/8" exceeds the capacity
code of the outdoor unit,
Ø5/8" Ø3/8"
apply the capacity code
Ø3/4" Ø3/8"
of the outdoor unit. (See
Table 1 and 2.)
