Step 1: Assembling the track components
20 28
20 28
Figure 1
THE FOLLOWING INSTRUCTIONS ARE FOR DRILLING THE MOUNTING HOLES TO MOUNT
THE #04400 MAST-R-FENCE III TO A NON-JESSEM TOP
NOTE: If you are mounting your Mast-R-Fence III to a JessEm top, please skip step 2.
NOTE: You will need to source (8) wood screws. The length of the screws will depend on the thickness of your
table top. Typically you would want screws that are about ¼" less than the thickness of your top. (Example: 1"
table top would require ¾" screws.)
Step 2: Marking and drilling your holes
20 18
20 18
Mark and drill 4 holes
on each side
Figure 2
ASSEMBLING THE MAST-R-FENCE III TRACKS
a.
Place
cap screws (part #29).
b.
Slide the screws through the slots in the left and right hand
fence track (part #18) See figure 1.
18
18
c.
Thread the square nuts (part #28) onto the screws. (DO NOT
29
29
tighten the square nuts).
23
23
d.
Slide the square nuts (part #28) into the T-slot in the mounting
angle (part #20) until the fence track is centred. See figure 1.
e.
Snug the
a.
Take one of your previously assembled track assemblies and
with a pencil, mark your holes on the underside of your table
top. Use the fence mounting angle (part #20) as a template.
See Figure 2.
NOTE: the mounting angles should be approximately
1-
b.
Pre-drill the holes using a
do not drill through the table top surface. It is suggested you
use masking tape on your drill bit to prevent this.
c.
Secure the track mounting angles to the table top with the #10
wood screws you sourced. Repeat this step for the other side.
7
⁄ " washers (part #23) onto the
1
4
⁄ "-20 X ⁄ " socket head cap screws (part #29).
1 5
4 8
⁄ " from the back of the table top.
1
4
⁄ " diameter drill bit and be sure you
1
16
⁄ "-20 X ⁄ " socket head
1 5
4 8
