Contents Of Packaging; Hardware Included - JessEm MAST-R-FENCE III Guide De L'utilisateur

5
4
36
33
Item No. Part Description
- MAST-R-FENCE III Assembly
2 Guard
5 Track Clamping Knob
9 Guard Mount
18 Fence Track
20 Fence Mounting Angle
33 Fence Shimming Bar
TOOLS REQUIRED FOR ASSEMBLY (SUPPLIED)
Item No. Part Description
- JessEm T-25 Torx Screwdriver
- ⁄ " Hex Key
3
16
- ⁄ " Hex Key
5
64
Item No. Part Description
1 Guard Height Adjustment Knob
4 Track Clamping Knob Washer
8 Guard Mount Clamping Knob
10 ¼"-20 X 1-½" Hex Head Screw
#10-24 X ½" Self Tapping Pan Head Torx Screw (Self tapping screws have a flat notch on
19
the end to facilitate cutting into the phenolic)
¼" Washer
23
28 ¼"-20 Square Nut
29 ¼"-20 X ⁄ " Socket Head Cap Screw
5
8
36 Fence Knob T-Nut
1 2
28
29 23

CONTENTS OF PACKAGING

HARDWARE INCLUDED

6
8 9
10
20 18
19
Qty
1
1
2
1
2
2
2
Qty
1
1
1
Qty
2
2
1
1
8
6
6
6
2
