Removing a paper jam
5
Precaution: Be very careful for the manual cutter mounted on the printer cover when removing and
replacing the cover, so as not to hurt yourself. Never touch the print head immediately
after printing, because the head may still be hot.
1.
Remove the printer cover.
2.
Pull the print head release lever toward you (to the head-up position). (Refer to the drawing on page 54.)
3.
Remove the paper jam. Check for and remove any shreds of paper that may remain in the printer.
4.
Return the print head release lever to its original position.
5.
Reset the paper roll correctly by following the steps in "Installing the paper roll".
Cleaning the print head
6
When the printed text is getting dark or faint, paper dust may be stuck to the print head. Clean the print head as
follows:
Roller
Thermal
head
Removing the till and the drawer
7
The till in the register is detachable. After closing your business for the day, remove the till from the drawer and
keep the drawer open. The 5-denomination coin case is also detachable from the till. To detach the drawer, pull
it forward fully with the till removed, and remove it by lifting it up.
Coin case
Till
Drawer
All manuals and user guides at all-guides.com
Precautions:
• Never touch the print head with a tool or anything hard as it may damage
the head.
• Be very careful for the manual cutter mounted on the printer cover when
removing and replacing the cover, so as not to hurt yourself.
1.
Turn the mode switch to the " " position.
2.
Remove the printer cover.
3.
Remove the inner cover that protects the printer (Press the lever, and lift it
up.)
4.
Pull the print head release lever toward you (to the head-up position). (Refer
to the drawing on page 54.)
5.
Clean the print head with a cotton swab or soft rag moistened with ethyl
alcohol or isopropyl alcohol.
6.
Return the print head release lever to its original position immediately after
cleaning.
7.
Replace the inner cover. (Insert the side tabs of the cover into their slots and
press the cover in the printer until it is properly seated.)
8.
Reset the paper roll correctly by following the steps in "Installing the paper
roll".
Bill case
Bill
separator
5-denomination coin case
(detatchable)
Coin case
1
2
57
