Connection block
CPX-P-AB-4xM12-
1)
4pol-8DE-N-IS
CPX-P-AB-4xM12-
2)
4pol
CPX-P-AB-2xKL-
1)
8pol-8DE-N-IS
CPX-P-AB-2xKL-
2)
8pol
1)
Suitable for connecting appropriate intrinsically safe field devices.
Only connection technology permitted in accordance with ATEX
special documentation!
2)
Only suitable for non-intrinsically safe circuits
3)
In order to ensure the housing protection class (IP code), the
tightening torque of the housing screws, plug connectors and
protective caps should be checked every six months.
Festo CPX-P-EA 1209NH English
Protection class
With mounted
plugs or protect-
ive cap ISK- M12,
mounted on inter-
linking block:
3)
IP65
At the terminal
connection
(2x pin strips,
8-pin) mounted
on interlinking
block: IP20
Connections
4 x sockets, 4-pin, A-coded,
M12X1 round plug connector
2 x COMBICON pin strips,
8-pin (grid = 5.00 mm)
