AXIS Q60 Series
Product
AXIS Q6042
AXIS Q6044
AXIS Q6045 Mk II
Connectors
SD Card Slot
Supports SD cards with up to 64 GB of storage. For best recording performance, use an SDHC
or SDXC card with speed class 10.
Install the Hardware
NO NO TICE NO TICE TICE
• Due to local regulations or the environmental and electrical conditions in which the
product is to be used, a shielded network cable (STP) may be appropriate or required.
All cables connecting the product to the network and that are routed outdoors or in
demanding electrical environments shall be intended for their specific use. Make sure that
the network devices are installed in accordance with the manufacturer's instructions. For
information about regulatory requirements, see Regulatory Information on page 2.
• Mount the product with the dome cover facing downward.
• Be careful not to scratch, damage or leave fingerprints on the dome cover because this
could decrease image quality. If possible, keep the protective plastic on the dome cover
until the installation is complete.
The Axis product can be installed with the cables routed through or along the wall or ceiling.
Read all the instructions before installing the product. Some installation steps would benefit from
being completed together because they require removal of the dome cover.
A hardware installation can include the following:
• The product is supplied with a clear dome cover (premounted). A smoked dome cover is
available as an accessory. To replace the dome cover, see page 19.
• A standard or high capacity SD card (not included) can be used to store recordings locally
in the product. To install an SD card, see page 19.
PoE+
DC
30 W
24–34 V DC,
max. 17.4 W
30 W 24–34 V DC,
max. 17.9 W
30 W 24–34 V DC,
max. 17.8 W
AC
20–24 V AC,
max. 24.7 VA
20–24 V AC,
max. 25.9 VA
20–24 V AC,
max. 26.0 VA
18
High PoE
midspan
(included)
100-240 V AC
max. 37 W
