Pay attention to the polarity marking given in the
battery compartment
• Empty batteries are not to be disposed of in the
household refuse, but they are to be handed in as
chemical waste.
Technical information
• Power supply: (2xAAA) batteries
• Frequence: 433.92Mhz
• Numbre of codes: 10
• Worktemperature: 0-50°C
• Dimensions: 110 x 50 x 19mm
3.4 InTouch
The cooker hood features the InTouch function. If you
have a Novy induction plate with InTouch, you can op-
erate the hood from the plate.
Programming InTouch on the induction plate
The remote control must first work with the hood. If
necessary, the remote control code can be changed,
as described in Section 3.3.
Connect the plate to the mains supply.
1. Touch the keys
and
duction plate until you hear a beep.
• The hob will now search automatically for the
hood code.
• WAIT until the hood lights flash, OR until you hear
8 clicks from the hood. (Be patient, this can take
a while)
2. Then touch any InTouch key
the induction plate until you hear a beep. This is the
confirmation of the pairing of both devices.
Now you can operate the hood with the keys on the
induction plate.
4 Maintenance
4.1 Grease filter
Maintenance of the grease filter
The hood contains two metal filters which should be
cleaned twice a month.
Grease filter indication
Indication: 4 flashing indicator lamps
After 20 cooking hours, the 4 indicator lamps will start
to blink during 5 minutes, this indicates that the grease
filter has to be cleaned.
simultaneously on the in-
or
or
or
on
Access to the filter
Take hold of the right and left side of the plate (A) and
pull down simultaneously. Remove the filter (B) by tak-
ing hold of its hook and pulling down.
Cleaning the filter
• in the dishwasher
• manually: in a hot solution of water and a liquid de-
tergent. Rince and allow to dry completely
The previous instructions need to be followed. If
not an increased fire hazard may occur.
Reset grease filter indication
When replacing the cleaned filter, you have to reset the
hood by pushing the – button during 5 seconds. If you
don't reset, the indicator lamps will continu blinking.
We advise you to clean your filter twice a month for an
optimal operation.
4.2 Recirculation (option)
Programme recirculation
When choosing for recirculation, always set the recircu-
lation program on the hood. Execute this programming
as follows:
• Do the programming with the motor switched off.
• Simultaneously press the + and the – keys for 5 sec-
onds until the red LED flashes 5 times.
The following functions have now been enabled:
• The run-out time has been set to 30 minutes (instead
of the default 10 minutes). Make use of the 30 min-
utes run-out time.
• The cleaning indicator for the Monoblock recircula-
tion filter has been set to 200 operating hours.
• Deactivate the recirculation:
• The motor must be switched off.
• Simultaneously press the + and the – keys on the
hood for 5 seconds until the third green LED flashes
3 times.
• The run-out time has been set to 10 minutes (instead
of 30 minutes). The cleaning indicator for recircula-
tion is off.
Cleaning indication
Indication: red indicator lamp lights up
The red indicator lamp will light up after 200 working
hours (time to regenerate the Monoblock recirculation
filter). The recirculation filter is to be found behind the
grease filter.
EN 19
