Opening the drawer by hand
6
The drawer automatically opens in the usual way. However, when power failure is encountered or the machine
becomes out of order, slide the lever located on the machine bottom in the direction of the arrow. (See the
figure shown below.) The drawer will not open, if it is locked with a drawer lock key.
ER-A160
Lever
Installing the fixing angle bracket
7
To prevent the register from moving when the drawer opens, use the supplied fixing angle bracket to fix the
drawer to the platform.
How to install the fixing angle bracket
1.
Thoroughly clean the location where the fixing angle bracket (B) is to be placed.
2.
Peel off the adhesive tape on the fixing angle bracket.
3.
Hook the angle bracket onto the hook (A) that is located at the bottom rear of the
register.
4.
Firmly stick the fixing angle bracket to the table surface that your cleaned above.
How to remove the register from the fixing angle bracket
1.
Lift up the front of the register and pull the register towards you.
42
Downloaded from:
http://www.usersmanualguide.com/
ER-A180
Lever
A
B
