ENGLISH
17 bypass function: : the icon indicates: (see also "Activation of bypass function" paragraph) off: bypass deactivated
permanently alight: bypass opened manually blinking: bypass opened automatically via software (in this case the
bypass cannot be closed manually).
18 °C indoor temperature
19 view outdoor temperature, °C
Switching on/off (fig.12)
12 12
FILT
1 2 3
esc
Prg
/ °C
By-Pass
Setting the time/day (fig.13)
13 13
FILT
1 2 3
esc
Prg
/ °C
By-Pass
Selezione velocità (fig.14).
14 14
FILT
1 2 3
esc
Prg
/ °C
By-Pass
P1 P2 HA
4 5 6 7
set
P1 P2 HA
4 5 6 7
set
P1 P2 HA
4 5 6 7
set
The appliance is switched on and off by pressing and holding the
DOWN button on the panel.
Before proceeding with the steps indicated below, press the ESC
button to exit and return to the initial menu.
The current time and day can be set as follows:
- press the UP and DOWN buttons together briefly;
- press the UP or DOWN button repeatedly to select the "hours"
setting (HH);
- press the SET button briefly to retain the "hours" setting and
move on to the "minutes" setting (MM);
- press the UP or DOWN button repeatedly to select the
"minutes";
- press the SET button briefly to retain the "minutes" setting and
move on to the "day" setting (dAy);
- press the UP or DOWN button repeatedly to select the "day"
setting;
- press the SET button briefly to retain the "day" setting and quit.
Before proceeding with the steps indicated below, press the ESC
button to exit and return to the initial menu.
The operating speed is preset during appliance configuration,
and can be selected by pressing the UP button briefly (1=min.
speed, 2=med. speed, 3=max. speed).
