Bellcome advanced Manuel De L'utilisateur page 18

Case
Mounting
Casing protection level (IP)
Operating temperature range
Range of transport and storage
temperatures
Dimensions
Weight
2.3 Technical features of the supply control unit
Supply tension
Generated power tensions/
power capability
Case
Mounting
Casing protection level (IP)
Operating temperature range
Range of transport and storage
temperatures
Dimensions
Weight
2.4 Technical features of the audio connection box
Main input – output
Branch
Case
Mounting
Casing protection level (IP)
Operating temperature range
Range of transport and storage
temperatures
Dimensions
Weight
ABS
Glass screen, 3 mm thick
Surface
IP31
0°C ... + 40°C
- 33°C ... + 55°C
171 x 96 x 30 mm
0,4 kg
230V±10%/50Hz
+14V – GND : +14Vd.c. (stabilised) / 2Ad.c.
+Uv – GND : +14Vd.c. (stabilised) / 0,5Ad.c.
Ucam – GND : +12Vd.c. (stabilised) / 0.2 Ad.c.
Fireproof ABS
On DIN rail: TH 35 x 15 or 35 x 7,5 in compliance
with DIN46277-3, EN50022, IEC60715
Surface: with A3,5 x 32 plastic screws and ø 6 mm pins
IP31
0°C ... + 40°C
- 33°C ... + 55°C
130 x 141 x 73 mm
0,4 kg
1
4
ABS
On DIN rail: TH 35 x 15 or 35 x 7,5 in compliance
with DIN46277-3, EN50022, IEC60715
Surface: with A3,5 x 32 plastic screws and ø 6 mm pins
IP31
0°C ... + 40°C
- 33°C ... + 55°C
100 x 71 x 60 mm
0,2 kg
