Using Heki4 Plus
Checking the remote control
You can check the remote control using a digital camera with a display:
➤ Point the infrared diode at the camera lens.
➤ Press a button on the remote control.
✓ If the remote control is working, you will see a light from the infrared diode on the
display.
Supplementary to fig. h
I
NOTE
You can only teach one remote control. If you want to teach another
remote control, the first remote control is deleted automatically.
The red control lamp (1) on the inner frame of the roof light is lit if the roof light is
open. It goes out when the roof light is completely closed and both runner wedges
are locked.
The red control lamp (1) flashes if the power supply to the roof light is interruptedand
then connected again.
Programming the remote control
➤ Point the remote control at the red control lamp of the roof light.
➤ Press the
" and
"
approx. 5 seconds.
✓ The red control lamp goes out:
Supplementary to fig. i
!
CAUTION! Beware of injury
The rain sensor closes the roof window if it is touched accidently.
To protect against dampness, the roof light is equipped with a rain sensor (1) which
closes the roof completely if it comes into contact with water (such as rain or conden-
sation).
If you want to stop the window from closing:
➤ Press
" or
" "
12
" buttons on the remote control at the same time for
"
" on the remote control.
Heki4 Plus
EN
