Technical description

6 Technical description

6.1 General description

The jump starter allows vehicles to be started without further assistance from third parties if a maximum peak current
of 1000 A is required to start the vehicle.
The jump starter is equipped with a lithium polymer battery and an integrated LED flashlight with continuous light,
strobe light and SOS signal for emergency situations.
With the two charging cables supplied, the device can be charged via the AC power supply or mobile via a 12 V
vehicle socket.
Digital mobile devices can be charged either by wireless or by one of the two USB outputs. In addition, the device
can be used to operate 12 V devices via the 12 V DC output.
The jump starter has the following protective mechanisms:
• High and low temperature protection
• Over current protection
• Low and over voltage protection
• Protection against short circuit
• Overcharge and deep discharge protection of the internal battery

6.2 Description of the device

Item in
fig. 2,
Designation
page 4
1
button
2 LCD display
3 Wireless charging pad
4 12 V DC output
5 Charging input
6.3 LCD display elements
Item in
fig. 3,
Description
page 4
1 Indicates the current state of charge in percent between 0 % (discharged) and 100 % (fully
charged)
2 IN: Indicates that the jump starter is being charged.
Note: The indicator flashes until the jump starter is 100 % charged.
3 OUT: Indicates that a device is being charged or a vehicle is being jump started.
4 Indicates the measured voltage and current of the digital mobile device connected (USB 1).
5 Indicates the measured voltage and current of the digital mobile device connected (USB 2).
6 16 V: Indicates that a 12 V device is connected (12 V DC output).
14
Item in
fig. 2,
Designation
page 4
6 LED flashlight
7 USB 1 output
8 USB 2 output
9 Jump-starting output (EC5)
