DIMAS DM 310
Operator's manual
Read these instructions carefully and make
sure you understand them before using
DM 310.
Manual de Instrucciones
Antes de utilizar DM 310 lea bien el manual de
instrucciones hasta comprender su contenido.
Bedienungsanweisung
Lesen Sie die Bedienungsanweisung sorgfältig
durch und machen Sie sich mit dem Inhalt
vertraut, bevor Sie DM 310 benutzen.
Manuel d'utilisation
Lire attentivement et bien assimiler le manuel
d'utilisation avant de se servir DM 310.

Publicité

Table des Matières
loading

Manuels Connexes pour Dimas DM 310

Sommaire des Matières pour Dimas DM 310

  • Page 1 Read these instructions carefully and make sure you understand them before using DM 310. Manual de Instrucciones Antes de utilizar DM 310 lea bien el manual de instrucciones hasta comprender su contenido. Bedienungsanweisung Lesen Sie die Bedienungsanweisung sorgfältig durch und machen Sie sich mit dem Inhalt vertraut, bevor Sie DM 310 benutzen.
  • Page 2 531 07 99-04 2003W10...
  • Page 3 Read the entire operator's manual Read, understand and follow all Always wear eye and ear before using or servicing this unit. warnings and instructions in this protectors when using this unit. manual and on the unit. Antes de utilizar o hacer el servicio Lea, comprenda y siga todas las Utilice siempre protecciones para de la máquina, lea en su totalidad...
  • Page 4 WARNING! Under no circumstances may the drills be modified from the original designs without the manufacturer’s approval. Unapproved modifications can result in serious personal injury or even death. WARNING! These drills can be dangerous if they are used improperly or without due care and such use can lead to serious accidents or, in the worst case, fatal accidents.
  • Page 5 Contents Safety Instructions _______________________________________________________________________ 6 Presentation ____________________________________________________________________________ 10 Technical Data __________________________________________________________________________ 11 What Is What? __________________________________________________________________________ 12 Operation ______________________________________________________________________________ 13 Care and Maintenance ____________________________________________________________________ 21 Compliance with EU Directives _____________________________________________________________ 24 Índice Instrucciones de seguridad ________________________________________________________________ 7 Presentación ___________________________________________________________________________ 10 Datos técnicos __________________________________________________________________________ 11 Componentes de la máquina _______________________________________________________________ 12 Manejo ________________________________________________________________________________ 13...

  • Page 6: Safety Instructions

    During the design and manufacture of Dimas products, great importance is placed on safety, as well as effectiveness and ease of use. This drill is for drilling in concrete, brick and various stone materials. All other use is improper.
  • Page 7 También es posible prevenir accidentes utilizando el sentido común. En el diseño y fabricación de los productos Dimas se ha puesto un gran énfasis en la seguridad, además de la efectividad y la facilidad de manejo.
  • Page 8 Darstellung aller möglichen Gefahrensituationen enthalten, die bei der Benutzung des Geräts aufkommen können. Wer jedoch stets den gesunden Menschenverstand einsetzt, kann Unfällen selbst vorbeugen. Bei der Konstruktion und Herstellung von Dimas Produkten wurde neben der Leistungsfähigkeit und Benutzerfreundlichkeit größtes Gewicht auf die Sicherheit gelegt.

  • Page 9: F Consignes De Sécurité

    Il est par contre possible de prévenir les accidents en faisant preuve de bon sens. Lors de la conception et de la fabrication des produits Dimas, un soin particulier a été apporté à la sécurité des machines, outre leur efficacité et leur simplicité d’utilisation.

  • Page 10: Presentation

    Fig. 1 Presentation The DM 310 is an electric drill, intended for drilling concrete, This drill is intended for stand-mounted drilling. The drill is brick and various stone materials. It is designed for quick equipped with Softstart™, an electronic current limiter, and and efficient work.

  • Page 11: Technical Data

    Rated Voltage _______________________ 110 V Stand Rated Current ______________________ 27 A The DM 310 can be used with the DS 500 stand (fig. 2). Rated Power ________________________ 3000 W Drill Diameter Max ___________________ 300 mm (12") Spindle Thread ______________________ 1 1/4"-7 UNC Water Connection ___________________ 1/4"...
  • Page 12 Technical Data (US, CAN) Spindle Speed, no load _______________ 350-750-1350-1900 rpm Spindle Speed, full load _______________ 230-480-870-1230 rpm Rated Voltage _______________________ 120 V Rated Current ______________________ 20 A Drill Diameter Max ___________________ 12" Spindle Thread ______________________ 1 1/4"-7 UNC Water Connection ___________________ 1/4" R Weight ____________________________ 26.6 lbs Sound Pressure Level ________________ 98 dB A, 98 dB C Sound Effect Level ___________________ 105 dB A-weight...
  • Page 13 Technical Data (AU) Spindle Speed, no load _______________ 350-750-1350-1900 rpm Spindle Speed, full load _______________ 230-480-870-1230 rpm Rated Voltage _______________________ 230 V Rated Current ______________________ 13 A Rated Power ________________________ 3000 W Drill Diameter Max ___________________ 300 mm (12") Spindle Thread ______________________ 1 1/4"-7 UNC Water Connection ___________________ 1/4"...

  • Page 14: Componentes De La Máquina

    Fig. 3 What Is What? a. Drill spindle b. Cooling system connector c. Screws holding together the gearbox and the motor (5 screws) d. Smartstart™ e. Switch f. Inspection hatches (2) g. Gear knob Componentes de la máquina a. Husillo de taladro b.
  • Page 15 Fig. 4 Operation • The drill and its equipment are correctly assembled: The drill bit is firmly attached. Before Starting The stand is firmly attached with an M12 bolt or Make sure that: similar. It is important that the stand is well anchored in order to carry out safe and effective drilling.
  • Page 16 Fig. 5 Fig. 6 • The connection is made using a protected, earthed Starting the Drill outletwith an output voltage that agrees with the voltage 1. Set the working speed by turning the drill spindle while that is stated on the plate on the underside of the drill moving the gear knob to the desired position (Fig.
  • Page 17 Drilling When drilling outdoors: Changing speed: • Always use extension cables that are approved for • Speed changes may only be made when the drill is outdoor use. switched off. When drilling in roofs and the like: • Check that the gear knob is in the right position when •...
  • Page 18 Using the Drill Consider the following when using the drill: Cooling: • When using Smartstart™, the drill has a very low power If necessary, run the drill unloaded for a minute or two to output. As a result, normal drilling cannot be carried out cool the motor.
  • Page 19 Slip clutch: Electronic overload protection: The drill is equipped with an electronic and a mechanical This protection comes into effect when the motor has been slip clutch. The electronic clutch makes the motor pulse overloaded for a short time. If the drill gets stuck in the when the drill is overloaded above a certain level.
  • Page 20 Fig. 7 Changing the Drill Bit 4. Apply water-resistant grease to the thread of the new In order to change the drill bit, do as follows: drill bit. 5. Attach the drill bit using the open-end spanner (Fig. 7). 1. Pull out the plug. Before the drill is started, carefully check that the new bit is 2.

  • Page 21: Care And Maintenance

    Electricity Supply • Inspect all cables, extension cables and outlets regularly The lifetime of the DM 310 can be extended considerably if in order to detect any damage or faults early. it is used, cared for and maintained in the proper manner.
  • Page 22 Fig. 9 Fig. 10 Changing the Gearbox Oil 4. Carefully disassemble the drill. The oil in the gearbox shall be changed after every 400 5. Pour the old oil into the container. hours of operation. Do as follows: 6. Pour the new oil into the gearbox, about1 litre, (top 1.
  • Page 23 Fig. 12 Fig. 11 Changing the Carbon Brushes 5. Pull the carbon brush out from the holder (III in Fig. 12). The carbon brushes shall be removed and inspected weekly 6. Insert the new carbon brush. Check that it slips easily if the drill is used daily.

  • Page 24: Compliance With Eu Directives

    Dimas AB, Box 2098, SE-550 02 Jönköping, Suède, tél.: +46 (0)36-570 60 00, certifie par la présente que le moteur de forage DM 310, à partir du numéro de série 01001 et au-dessus, est fabriqué en conformité avec les directives du conseil, à savoir les directives Machines 98/37/CE, Basse Tension 73/23/CEE et Compatibilité...
