Service Parts; How To Use This Manual - Textron Jacobsen PGM Serie Manuel Technique

To Keep your Equipment fully operational and productive, maintain a stock of the more commonly used maintenance
items. We have included part numbers for additional support materials and training aids. A more complete listing of
accessories and attachments can be found in the Specifications Section.
Qty. Part No.
5002605 11 Blade Reel
503477 22" High Profile Bedknife
503478 22" Low Profile Bedknife
503479 22" Tournament Bedknife
5002887 22" Super Tournament Bedknife
366648 Seal, Grease
3006511 Washer
337677 Seal, Oil
Qty. Part No.
4131595 Technical Manual
Abbreviations
N/S - Not serviced seperately, can only be obtained by ordering main component or kit.
AR -Variable quantity or measurement is required to obtain correct adjustment.
Symbols such as ▲, next to the item number, indicate that a note exists which contain additional information
important in ordering that part.
Indented Items
Bulleted items indicate component parts that are included as part of an assembly or another component. These parts
can be ordered separetely or as part of the main component.
Item Part No.
▲
1 123456
2 789012
3 345678
4 N/S
5 901234.6
All manuals and user guides at all-guides.com
Description
Description
Qty Description
1 Mount, Valve
1 Valve, Lift
1 • Handle
1 • Seal Kit
1 Screw, 1/4-20 x 2" Hex Head
Suggested Stocking Guide
Qty. Part No.
101804 Spider
102098 Pinion, Idler
202947 Pinion
164056 Brake Band
Service Support Material
Qty.
Service Manual
Operator Training Video

How To Use This Manual

Serial Numbers/Notes
Indicates a piece part
Includes Items 2 and 3
Serviced part included with Item 2
Non serviced part included with Item 2
Indicates a part painted Jacobsen Orange

Service Parts

Description
Description
3
