INSTALLATION MANUAL
CBB
Self-contained Keypad - braille keys
3] MOUNTING KIT
CBB
4] MOUNTING INSTRUCTIONS
Once you have made sure that the mounting kit is complete and that you prepared the cables
of the CBB keypad then you can proceed and mount the product. Make sure that you have
all the appropriate tools (drill, screw drivers and a meter tape...) and follow the mounting
instructions of for the CBB keypad.
1
Take the fl ush casing to measure and
mark the mounting holes. Then drill the 4
mounting holes and the wiring access area.
All manuals and user guides at all-guides.com
DIAX
screw
®
(M5x16)
1
2
Mount the back casing of the CBB
and the electric cable from the wiring
access area.
DIAX
screw
®
spanner
(ODIAX tool)
1
3
Finally Mount the CBB with the DIAX
screw.
EN
05D 680K
Varistor
1
®
cdvi.com
13
cdvigroup.com
