Assembly Components; Steering Wheel Assembly; Seat Assembly; Mounting The Grass Catcher Bag - Stiga R72 Li 48 V1 Manuel D'utilisation

the machine and its packaging, always
making use of suitable equipment.

5.1 ASSEMBLY COMPONENTS

The packaging holds the components needed
for assembly as listed in the table below:
Description
1 Steering wheel and
mounting components
2 Driving seat
3 Battery charger
4 Bag with mounting nuts and
bolts and instructions
5 Envelope containing:
- the instruction manuals and documents
- driving seat assembly screws
- 2 starter keys
6 Mobile phone holder kit (if provided).
5.1.1 Unpacking
1. Carefully open the packaging, paying
attention not to lose components.
2. Consult the documentation in the
box, including these instructions.
3. Remove all the unassembled
parts from the box.
4. Remove the machine from the packaging
taking the following precautions:
• move the cutting means assembly
to its maximum height (par. 6.4) to
protect it against damage when the
machine is lifted off the base pallet;
• Move the front drive release lever to
the released position (par. 6.3);
• Lift the machine off the base pallet.

5.2 STEERING WHEEL ASSEMBLY

First of all, put the machine on a flat surface
and straighten the front wheels. Then:
Only for type "I" steering wheel
1. Fit the support (fig. 3.B) on the
steering shaft (fig. 3.A).
2. Fit the hub (fig. 3.C) on the steering
support (fig. 3.B) making sure that
the pin (fig. 3.G) is correctly inserted
into its seat (fig. 3.C) in the hub.
3. Fit the steering wheel (fig. 3.D) on
the hub (fig. 3.C) with the spokes
pointing towards the seat.
4. Fasten the steering wheel (Fig. 3.C) on the
support (Fig. 3.D) using the supplied screws
(Fig. 3.E) in the sequence indicated.
5. Replace the cap on the steering wheel
(fig. 3.I) inserting with a click into its seat.
Only for steering wheel type "II"
1. Fit the hub (fig. 3.B) on the steering shaft
(fig. 3.A) making sure that the pin (fig. 3.C)
is correctly inserted into its seat in the hub.
2. Fit the steering wheel (fig. 3.D) on
the hub (fig. 3.B) with the spokes
pointing towards the seat.
3. Fasten the steering wheel (Fig. 3D) on the
support (Fig. 3A) using the supplied screws
(Fig. 3.E) in the sequence indicated.
4. Fit the mobile phone holder (fig. 3.F)
making sure that it is correctly inserted in
its seat on the steering wheel (fig. 4.F, D).
5. Fit the mobile phone holder cap (fig. 3.G)
making sure that it is correctly inserted in
its seat on the steering wheel (fig. 4 G, .F).

5.3 SEAT ASSEMBLY

Mount the seat (fig. 5.A) on the base plate
(fig. 5.B) using the screws (fig. 5.C) and the
other small parts supplied (fig. 5.E) in the se-
quence indicated.
5.4 MOUNTING THE GRASS
CATCHER BAG
1. Insert the canvas (fig. 8.A) for the
grass catcher on the frame (fig.
8.B)and secure it with the specific
perimeter closures (fig. 8.D).
2. Fit the cover (fig. 8.C) on the frame (fig.
8.B) using the screws supplied in the
quantity and positions indicated.
3. Secure the canvas (fig. 8.A) on the cover
(fig. 8.C) using the rings supplied (fig. 8.E)
in the quantity and positions indicated.
EN - 10
