Optional Side Force Generators (SFGs) Installation

Side Force Generators add side force in all fl ight
attitudes, increase rudder authority and make a
variety of aerobatics possible.
1. Slide the SFG slot on the wing so the lower half
of the SFG is under the carbon wing supports.
2. Turn the SFG carefully so the carbon supports
fit into the SFG.
3. Secure the SFGs to the wing and carbon
supports using foam-safe CA (cyanoacrylate
adhesive).
NOTICE: Install the SFGs vertically on the wing.
Failure to install the SFGs at a 90º angle may result
in incorrect fl ight performance.

Control Direction Test

You should bind your aircraft and transmitter before
doing these tests. Move the controls on the trans-
mitter to make sure the aircraft control surfaces
move correctly and in the proper direction.
8
All manuals and user guides at all-guides.com
Make sure all linkages move freely.
