Fireplace Installation (continued)
For Bathroom Use
If this unit is installed in a
bathroom it must be protected
by a GFCI receptacle or circuit.
If receptacle is used it must be
readily accessible.
This electrical appliance is NOT
watertight. To prevent electric
shock, it must be installed as to
prevent water from entering unit,
or installed away from showers,
tubs, etc. Never locate fireplace
where it may fall into a bathtub or
other water container.

Final Assembly

1. Locate and remove the screws
securing the partially reflective
glass bracket to the unit
(Figure 7), along the top of the
opening, and set bracket and
screws aside.
2. Remove the provided suction
cup from the inside cavity of the
unit (not found in REL5 units).
3. Before installation ensure that
the front glass and the partially
reflective glass are clean.
Particles can be removed by
dusting lightly with a clean dry
cloth. To remove fingerprints
or other marks, the glass
can be cleaned with a damp
12
cloth. Ensure that the glass
has completely dried before
installation.
4. Carefully secure the suction cup
to the partially reflective glass
on the reflective side, and place
into the openings on either side
of the unit.
5. Tip the glass into the unit and
using the removed screws
secure the glass into the unit
with the provided bracket
(Figure 7). Remove the
suction cup.
6. Evenly space the large media
in the media tray along the back
of the media tray (for optimum
media effect), then carefully
pour and evenly distribute
the smaller media into the
Media Tray.
7. Carefully place the front glass
into the lip located at the bottom
of the opening of the firebox.
8. Tip the front glass into the
unit and secure using the
provided screws and Allen key.
(Figure 8).
!
NOTE: Ensure that the suction
cup and Allen key are kept for
any future maintenance
or service.
