15. Technical data

a) Outdoor unit
Operating voltage ...........................5 V/DC
Power consumption ........................max. 600 mA
Network ..........................................RJ45, 10/100 MBit
WLAN .............................................2.4 GHz, 802.11b
Transmission protocol.....................P2P
Image sensor ..................................6.35 mm (1/4"), CMOS WXGA, colour
Effective resolution .........................640 x 480 (horizontal x vertical); 30 FPS
Video encoder ................................H.264
Opening angle ................................90°
Operation in darkness ....................yes; IR-lighting with 5 LEDs; on < 20 Lux; off > 25 Lux;
Range IR ........................................30 - 40 cm
Bell button lit ...................................yes
Name sign lit ...................................yes
Door opener contact .......................potential-free relay
Contact resilience ...........................max. 15 V (AC/DC), max. 2 A
Degree of protection .......................IP24
Installation/operation site ................protected outdoor area
Supported operating systems .........Android 2.3 or higher; Apple iOS 6 or higher
TM
Dimensions (W x H x D) .................approx. 84 x 160 x 48 mm
Weight ............................................approx. 227 g (outdoor unit incl. wall holder)
Operating conditions .......................-10 °C to 50 °C, humidity 0% to 85% relative
Storage conditions ..........................-20 °C to 60 °C, humidity 0% to 85% relative
b) Mains adapter
Operating voltage ...........................100 - 240 V/AC, 50 - 60 Hz, max. 300 mA
Output .............................................5 V/DC, 1 A
