6.3 Fitting the battery

CAUTION
Before fitting the battery, check that the power tool is switched
off and that the safety lock is engaged (forward/reverse switch
in the middle position). Use only the Hilti batteries approved
for use with this power tool.
CAUTION
Check that the terminals on the battery and in the power tool
are free from foreign objects before inserting the battery in
the power tool.
1. Push the battery into the power tool from the rear as far as it
will go and until it is heard to engage with a double click.
2. CAUTION If it is not fitted securely, the battery could fall
out while you are working with the tool.
CAUTION A falling battery may present a risk of injury to
yourself or others.
Before beginning the work, check that the battery is fitted
securely to the tool.
6.4 Removing the battery 2
1. Press both battery release buttons.
2. Pull the battery out of the power tool toward the rear.
6.5 Transport and storage of battery packs
Pull the battery pack out of the locked position (working position)
and move it into the first click-stop position (transport position).
If you disconnect a battery pack from the power tool for transport
or storage, make sure that the contacts of the battery pack are
not short-circuited. Remove loose metal parts such as screws,
nails, clamps, loose screw bits, wires or metal swarf from the case,
toolbox or transport container, or prevent these parts from coming
into contact with the battery packs.
Observe national and international transport regulations when
shipping battery packs (transportation by road, rail, sea or air).
7 Operation
7.1 Changing sockets
NOTE
To ensure that the socket is held securely, the tool is equipped
with a ½" square drive with ball-notch retention or a ¾" square
drive with locking pin.
7.1.1 Changing the socket (½" square drive with ball-notch
retention)
NOTE
Bring the notch in the socket into alignment with the ball on the
square drive before fitting it to the power tool. The socket will not
be held securely and could fall off inadvertently if this point is not
observed.
7.1.1.1 Fitting the nut driver 3
1. Set the forward / reverse switch to the middle position or
remove the battery from the power tool.
2. Align the hole in the side of the nut driver with the retention
ball on the square drive.
3. Push the nut driver onto the chuck until it engages.
7.1.1.2 Removing the socket 4
1. Set the forward / reverse switch to the middle position or
remove the battery from the power tool.
2. Pull the socket away from the square drive spindle.
