Tableau 23. Exemple de configuration en cours sur les commutateurs ToR
Commutateur 1
flowcontrol transmit off
!
interface ethernet1/1/25
description VLTi
no shutdown
no switchport
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/26
description VLTi
no shutdown
no switchport
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/29
description Uplink_Ports
no shutdown
channel-group 30 mode active
no switchport
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/30
description Uplink_Ports
no shutdown
channel-group 30 mode active
no switchport
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/31
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/32
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/33
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/34
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/35
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/36
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
Autres opérations de configuration de commutateurs Dell EMC PowerSwitch Series S4148-ON
Commutateur 2
flowcontrol transmit off
!
interface ethernet1/1/25
description VLTi
no shutdown
no switchport
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/26
description VLTi
no shutdown
no switchport
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/29
description Uplink_Ports
no shutdown
channel-group 30 mode active
no switchport
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/30
description Uplink_Ports
no shutdown
channel-group 30 mode active
no switchport
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/31
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/32
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/33
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/34
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/35
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
interface ethernet1/1/36
shutdown
switchport access vlan 1
flowcontrol receive off
flowcontrol transmit off
!
