Trouble-Shooting; Dab Digital Radio; Factory Reset; Technical Specification - Revo Uno2 Mode D'emploi

English

Trouble-Shooting

DAB Digital Radio

Q. I hear a 'burbling' noise on some
stations.
A. If the signal strength is too low, a break-
up in reception can occur. This sound is
the result. Make sure that Uno's antenna
is fully extended and in an upright
position. If the problem persists, move
Uno to another location or check that
you are in an area where reception of
this station is possible.

Factory Reset

In the unlikely event that Uno performs erratically, it is possible to perform a software
reset to restore the original factory settings. The factory reset option can be found under
the System Setup heading, which itself can be found under the Main Menu.

Technical Specification

General:
Speaker:
Audio Power Output:
Frequency Ranges:
Antenna:
Input Connectors:
Output Connector:
LCD Display:
Alarm Clock:
Presets:
Remote Control:
Mains Power Supply:
Approvals:
Dimensions:
10
Q. I get a 'No stations available' message?
A. Make sure that your antenna is fully
Q. Uno's clock isn't set.
A. Uno needs to be able to pick-up a DAB
Mono DAB and FM radio with full Band III reception.
2" full-range neodymium, 8W power handling
2W
DAB Band III (174 - 240 MHz)
DAB+ coverage
FM (87.5 - 108 MHz)
Integral telescopic aerial
DC power adaptor socket (230V adapter supplied)
3.5mm line-in for auxiliary devices (M-Port)
3.5mm headphone socket
Double height, high resolution negative display with
digital clock, status icons and two information lines
Alarm clock with snooze and sleep functions
10 x DAB and 10 x FM presets
Infra-red remote control
12V 1.2mA
CE marked and RoHS compliant.
167mm (H) x 105mm (W) x 105mm (D)
extended and vertical. Check the signal
strength and move Uno to another
location if necessary.
signal or have its clock set manually.
If Uno can find a DAB station, it can then
set its clock.
