Assembly And Operating Parts; How The Voss.sonic 1000 Works; Important Notice - VOSS .sonic 1000 Notice D'utilisation

1.5 CONTENTS
1 x VOSS.sonic 1000 ultrasonic repeller (45016) or 2 x VOSS.sonic 1000 ultrasonic repeller (45016.2)
1 x operating instructions
1 x mounting post
2. OVERVIEW OF THE DEVICE AND ITS FUNCTIONS

2.1 ASSEMBLY AND OPERATING PARTS

Speaker
Frequency and ON/OFF dial
IR-Range dial
Motion detector
Function control LED, lights up
red when triggered
2.2 HOW VOSS.SONIC 1000 WORKS
As soon as the motion sensor is activated, the device starts to emit a series of ultrasonic sounds based on the respective
setting of the „Frequency" dial. The animals will not stay in the area where they can hear the sounds, since they are very
unpleasant to them. The sound will only be triggered if an animal enters the operational area. This prevents the animals from
becoming accustomed to the noise, which further increases the repellent effect.

Important notice

The repeller emits ultrasonic sounds that are inaudible or barely audible to humans. According to the current research,
ultrasound does not cause any damage if the maximum level is below 140 dB and the average level, based on 8 h/day, is
below 110 dB. Our devices emit ultrasonic sound with the noise levels ranging between 80 and 120 dB. Continuous
operation of the units is not possible.
Ultrasonic waves can penetrate light building materials. The efficiency of the ultrasonic signal behind solid objects is
reduced. It may be necessary to set up several units to ensure complete coverage.
Explanation of the product labels
Symbol Meaning
Disposal of electrical goods
Compliance of the product with the EU directives
Operate only in dry environments
10
INSTRUCTION MANUAL VOSS.SONIC 1000
Connection for
mains adapter
Opening for the mounting post
45016/09/2020/V3
