Fitting Instructions - gdw 0477 Instructions De Montage

Mercedes Sprinter pick-up
1995 - 1998
Ref. 0477

Fitting instructions

1) Remove the spare wheel and permanently remove the towing ring, on the right at the back.
2) Place the tow bar against the inside of the chassis beams, so that points (A) fit the provided holes in the
chassis beams.
Place on the outside of the chassis beams the mounting pieces (e), insert the bolts, washers and nuts and
tighten firmly.
3) Install the (*) and also tighten firmly.
4) Reinstall the spare wheel.
Composition
1 tow bar reference 0477
1 flange ball 50T90
2 bolts M16x50
2 safety washers M16
2 nuts M16
1 security shackle 50T
8 bolts M12x90
8 safety washers M12
8 nuts M12
2 mounting pieces (e)
All bolts and nuts: quality 8.8
Note
Please consult your cardealer or owners manual for the maximal permissable towing mass.
Remove any bitumen coating on the fastening position for the tow bar.
When drilling, be carefull not to damage any brake lines, electrical wiring or fuel lines.
(*)
(*)
(*)
(*)
(*)
(A)
(A)
(A)
(A)
