Installation
ARNU363B8A4, ARNU423B8A4, ARNU483B8A4, ARNU763B8A4,
ARNU963B8A4
Valeur de réglage
6(0.23)
60
40.5(1430)
65
52.7(1861) 39.3(1388)
70
63.7(2249) 47.1(1663)
75
71.1(2511) 56.9(2009) 44.7(1578)
80
76.3(2694) 69.7(2461) 55.2(1949)
85
83.3(2941) 78.6(2775) 67.4(2380) 55.9(1974) 31.8(1123)
91
89.7(3167) 87.1(3076) 78.9(2786) 67.6(2387) 54.2(1914)
95
93.4(3298) 91.4(3227) 86.1(3040) 77.0(2719) 66.4(2345) 50.6(1787) 30.0(1059)
100
93.4(3298) 91.4(3227) 88.3(3118) 84.9(2998) 75.9(2680) 69.5(2454) 60.8(2147) 43.1(1522)
105
93.2(3291) 91.3(3224) 88.3(3118) 84.9(2998) 81.1(2864) 77.4(2733) 72.0(2542) 68.0(2401) 52.0(1836)
Note:
1. The above table shows the correlation between the air rates and E.S.P.
2. The above table shows the available E.S.P. range.
3. If the E.S.P. of the installed indoor is less than the lowest value(as mention in the table), indoor components can be failed.
26
Unité intérieure
Static Pressure(mmAq (in.Aq))
9(0.35)
12(0.47)
15(0.59)
-
-
-
-
-
-
-
-
-
18(0.71)
20(0.79)
22(0.86)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
(Unité: CMM(cfm))
23(0.90)
25(0.98)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
