LED signals on the sensor
LED signal on the sensor
LED is not illuminated
Green LED is illuminated
Green LED is flickering
Green LED is flashing quickly
Green LED is blinking once
per second
Red LED is blinking once per
second
Red LED is flashing quickly
Red LED is illuminated*
32
Meaning
The sensor has a functional connec-
tion and is delivering measurements
to the measuring instrument.
The sensor has a functional con-
nection and is being addressed via
sensor info by the HPM6000.
The sensor has a functional connec-
tion and is being configured by the
HPM6000.
The sensor is ready to be configured.
The sensor has a functioning connec-
tion but is not currently delivering any
configuration or measurement data.
The sensor does not have a function-
ing connection.
A sensor configuration error has oc-
curred.
The sensor is not functioning because
the CAN interface has been deacti-
vated due to continued errors.
