Surge
High-frequency,
conducted
Disturbance emis-
sions
Interference current,
DC supply
Radiated emissions
CANopen interface
Protocol
Device profile
Special functions
Response time
Pressure
Accuracy
Pressure (full scale)
Temperature
DIN EN 61000-4-5 DC current grid for inputs
DIN EN 61000-4-6 10 V, 150 kHz – 80 MHz,
DIN EN 55011
DIN EN 55022
DIN EN 55011
DIN EN 55022
DS 301 v4.1, type 2.0 A
DS 404 v1.2
LSS according to DS 305 v2.0
1 ms
0.25% ave.
0.5% max
+/- 2 K ave.
+/- 3 K max.
and outputs
0.5 kV symmetrical
0.5 kV unsymmetrical
EM coupling clamp
150 kHz – 30 MHz
Current probe
30 MHz – 1 GHz
Anechoic room
