6 Parameters
6.1 Description of parameters relevant to ACT
The parameters are partly set via the guided commissioning. The
following overviews refer to configurations 110 and 410. For
additional configurations enabling setting of other parameters, refer
to the Operating Instructions.
6.1.1 Adjustable parameters
No. Description
28 Control Level
30 Configuration
34 Program(ming)
369 Motor Type
370 Rated Voltage
371 Rated Current
372 Rated Speed
374 Rated Cosine Phi
375 Rated Frequency
Rated mech.
376
Rated power
Switching
400
frequency
12/20
Adjustable parameters
Unit
These instructions describe the parameters on
Control Level 1. Higher control level parameters
-
are described in the Operating Instructions and
should only be set by expert users.
The basic function of the control inputs and
outputs as well as the assignment of the software
- modules is selected by the configuration. The
selection is made during the guided
commissioning.
The factory settings of all parameters is restored
- or a fault message is acknowledged (alternative to
signal at digital input SIND1).
Selection of connected motor or transformer. The
- selection is considered in the test of the entered
rated values and the guided commissioning.
Enter the voltage indicated on the type plate of
V
the asynchronous motor.
Enter the rated current indicated on the type plate
A
of the asynchronous motor for the selected circuit.
Enter the motor speed indicated on the type plate
RPM
of the asynchronous motor at rated frequency.
Enter the cos(ϕ) value indicated on the type plate
-
of the asynchronous motor.
Enter the rated frequency (at parameterized rated
Hz speed) indicated on the type plate of the
asynchronous motor.
Enter the power (in KW) indicated on the type
kW
plate of the asynchronous motor.
Higher switching frequencies reduce the motor
Hz noise, but reduce the output current (refer to
technical data in Operating Instructions)
