Dimensions without optional components [mm]:
Size a
190
1
250
2
3 250
4 250
5 250
400
6
12/20
Dimensions
b c
60 178
60 178
100 200
125 200
200 260
275 260
Quick Start Guide ACT
Assembly dimensions
a1 a2
210...218 230
270...274 286
270...290 315
270...290 315
270...290 315
425...445 470
Top screw fixture
M5x20
Bottom screw
fixture M5x20
Screw fixing
brackets to heat
sink of frequency
inverter and
mounting plate.
b1 c1
30 133
30 133
12 133
17.5 133
20 160
20 160
63
