Components
Ref.
Qty.
Product Components
1
1
Hood Body, complete with: Con-
trols, Light, Filters, Blower.
2
1
Frame
8
1
Recirculation Vent Grill
10
1
Damper ø 5 7/8"
Ref.
Qty.
Installation Components
12a
10
Screws (for hood installation)
12e
2
Screws 1/8"x3/8" (for Recircula
tion Vent Grill mounting)
12f
6
Screws 1/8"x1/4" (for frame
mounting)
Qty.
Documentation
1
Instruction Manual
- 6" Round Metal ductwork .
Direct Connect Wiring Box sku # number: WIREBOX
Liner 30" Stainless #LINE30ST
Liner 36" Stainless #LINE36ST
6" Make-Up Air Damper Kit #MUDAMPER6
8" Make-Up Air Damper Kit #MUDAMPER8
Activated Charcoal Filter sku #; FILTER1
Activated Charcoal Filter sku #; FILTER1LL
CFM Reducer Kit #CFMRED
Remote Control Accessory - REMCTRL
6
MAIN PARTS
Parts needed
Available Accessories
-
