G2424-S200
For more information, consult the website:
www.atlascopco.com
Choose Products - Safety Data Sheets, and follow the instructions on the page.
Country of origin
Please refer to the information on the product label.
Dimensional drawings
For information about the dimensions of a product, see the Dimensional drawings archive:
http://webbox.atlascopco.com/webbox/dimdrw
Overview
Design and function
This die grinder is intended for mounted wheels and rotary burrs only. This model is lubricated. The ma-
chine, its attachments and accessories must only be used for the purpose for which they were designated,
all other use is prohibited.
■ Never use grinding wheels attached with an adapter as this machine is not fitted with a wheel guard
■ Never attach circular saw blades or other cutters than the abrasive wheels or brushes specified for
the tool
Technical data
The table below shows the technical data for this product.
Ordering No
Model
Air consumption at free speed
Air consumption at max output
Max working pressure
Air inlet thread
Max free speed
Max output
Motor type
Recommended hose size (d x l)
Weight
Technical data
Ordering No
Model
Max wheel diameter
Max pad diameter
Spindle thread
Spindle length
Air inlet thread
Air consumption at free speed
Air consumption at max output
Max working pressure
EN
© Atlas Copco Industrial Technique AB - 9839 0487 00
8423031255
G2424-S200
9.0 l/s (19.1 cfm)
19.0 l/s (40.3 cfm)
6.3 bar (90 psig)
3/8"
20500 r/min (rpm)
0.85 kW (1.16 hp)
Vane
13 mm x 3 m (1/2" x 12")
1.0 kg (- lb)
8423031255
G2424-S200
mm ( in)
- mm (- in)
mm ( in)
3/8 in
9.0 l/s (19.1 cfm)
19.0 l/s (40.3 cfm)
6.3 bar (90 psig)
Product information
