All operating elements and connections de -
scribed can be found on the fold-out page 3.
1 Operating Elements
and Connections
1 Receiving antennas
2 IR transmitting diode
3 Button ADL, to transfer the radio frequency of
the receiver to the transmitter by IR signal; set-
tings for the transmitter (transmission power
and gain) made on the receiver will also be
transferred
4 Display (
fig. 3 and chapter 1.1)
5 Buttons SET, AUTO,
Automatic lock function:
A short while after switching on and after the last
operation, the buttons SET, AUTO,
be locked automatically (lock symbol
display). To unlock the buttons or to lock them
again, keep the button SET pressed for approx.
1 second.
1. Setting mode: When the buttons are un -
locked, use the button SET to call up the fol-
lowing functions one after another:
Group setting → channel setting → squelch setting
→ setting of transmission power for the transmitter
→ gain setting for the transmitter → exit of setting mode
As long as the indication of the function
selected keeps flashing, settings can be
made with the buttons
1.1 Display
Indication
and
and
will
on the
and
.
Function
strength of the radio
signal received
volume of the audio
signal received
radio frequency
group
channel
indicates
the battery status
of the transmitter
in several levels
2. Volume: When the buttons are unlocked, use
the buttons
output signal of the receiver (range 0 ... 63).
3. Automatic channel scan: When the buttons
are unlocked, press the button AUTO to start
the channel scan within a group.
6 Button POWER to switch the receiver on / off
(keep button pressed for approx. 1 second)
7 Power supply jack to connect the power supply
unit provided
8 Audio outputs, one each for connection to a
microphone input or to a highly sensitive line
input (e. g. of a mixer or amplifier)
– XLR chassis plug, balanced
– 6.3 mm jack, unbalanced
9 Antenna inputs A and B (BNC jacks)
Indication
Function
an antenna symbol will indicate the receiver
section (A or B) receiving the radio signal of
the highest quality
wave symbol will pulsate during IR transmission
starts flashing during the channel scan
squelch, adjustable in 3 levels
buttons SET, AUTO,
setting for the transmitter:
transmission power, adjustable in 3 levels
setting for the transmitter:
matching of volume level (0 dB, -3 dB, -6 dB)
and
to set the volume for the
,
locked
GB
9
