Connection
13 SDI Outputs
14 Stereo L/R In
15 Analog Audio In (XLRF)
a. Support for 3D frame compatible (over/under, side-by-side). We do not support full frame

Connecting Avid Artist DNxIQ

Use the following procedures to connect the Avid Artist DNxIQ hardware to your computer, install
the Media Composer software and install the Desktop Video software.

Connecting Avid Artist DNxIQ to Your Computer

You can connect the Avid Artist DNxIQ to your computer through a Thunderbolt connector or
through a PCIe connector.
n
For customers that require Thunderbolt connectivity over longer distances than standard 2 meter
copper Thunderbolt cables, Avid has tested and qualified 30 meter and 60 meter optical Thunderbolt
cabling offered by Corning. For more information, please visit
To connect through the Thunderbolt Connector:
1. Connect a Thunderbolt cable between the Artist DNxIQ and a Thunderbolt port on your
computer.
2. For redundant power, use the 2 supplied power cords to connect the Artist DNxIQ hardware to
AC power.
To connect through a PCIe Connector:
1. Make sure the PCIe card is installed in your host computer. See the documentation supplied with
your host computer for information on installing a PCIe card. The PCIe card should be installed
in a Gen 3 x4 PCIe slot in the system, or a Gen 2 x4 PCIe slot if Gen 3 not available.
2. Connect one end of the PCIe cable to the PCIe card in the host computer and the other end to the
PCIe connection on the Artist DNxIQ.
3. For redundant power, use the 2 supplied power cords to connect the Artist DNxIQ hardware to
AC power.

Installing Avid Media Composer Software

If Media Composer is already installed on your system, go to
Software" on page
software.
Description
Two 12 Gb/s and two 3 Gb/s connectors (SD/HD/2K/UHD/4K)—
supports single, dual and quad link outputs (4:2:2 / 4:4:4); 2D/3D
switchablea—When using single link 6G or 12G or dual 6G on A and/or
B, output C and D will be downconverted 3G.
Stereo RCA input for consumer audio devices.
Four channels of professional balanced analog audio input via XLR;
8. If Media Composer is not already installed on your system, you must install the
Connecting Avid Artist DNxIQ
www.opticalcablesbycorning.com
"Installing the Desktop Video
