MODELS: ZRV-E30AGC, ZRV-M90AGG
ZRV-E30AGC, ZRV-M90AGG
PARTS SUPPLIED
HARDWARE PACKAGE CONTENTS
(3) M6 x 1-1/2" (3) M6 x 1"
(3) Wire Nuts
PARTS NOT SUPPLIED
- Ducting, conduit and all installation tools
- Cable connector (if required by local codes)
- Duct cover extension accessory
- Recirculating kit accessory
1 - Duct cover wall bracket
1 - Duct cover assembly, top and bottom
1 - Hardware package
1 - 6" round damper, pre-installed
1 - Hood body with internal blower
1 - Glass Canopy
2 - 50W halogen light bulbs
1 - Aluminum mesh filter
(4) 3/16 x 1/4 pan-head
(2) M3.5 x 8
machine screws
(1) ø12 OD / ø5 ID (1) Light Bulb Removal
Washers Suction Cup
4
