PACKAGE CONTENTS
PART DESCRIPTION
Discharge Tube - This tube carries compressed air from the pump to the check
C valve. This tube becomes very hot during use. To avoid the risk of severe burns,
never touch the discharge tube.
Check Valve - One-way valve that allows air to enter the tank, but prevents air in the
D
tank from flowing back into the compressor pump.
E Belt Guard - Covers the belt, motor pulley and flywheel.
Tank Drain Valve - This valve is located on the bottom of the tank. Use this valve to
F
drain moisture from the tank daily to reduce the risk of corrosion.
G Tank Pressure Gauge - Indicates amount of air pressure stored in the tank.
H Air Filter - Keeps large particulates out of the air flowing into the compressor.
I Breather - Vent for crankcase.
J Oil Fill Port - Port used to refill the oil in the pump after oil changes or when oil is low.
K Pump - Cast Iron 2-Stage air compressor pump that generates compressed air.
L Motor - Power source that drives the pump to create compressed air.
Tank Outlet - This is where you plumb into to get compressed air from the pressure
M tank. An isolation valve should be installed here to be able to shut off the air supply
from the tank.

PREPARATION

Before beginning installation and/or assembly of product, make sure all parts are present. Compare
parts with package contents list. If any part is missing or damaged, do not attempt to assemble or use
the product.
WARNING
Risk of Personal Injury. Do not operate unit
if damaged during shipping, handling or use.
Damage may result in bursting and cause
injury or property damage.
Estimated Installation and Assembly Time: 120 minutes
Tools Required for Installation and Assembly (not included): Safety Glasses; Work Gloves; 9/16 in.
Socket and Ratchet; Tape measure; Hammer Drill and Masonry Bit; Hammer; Phillips Screwdriver;
Flathead Screwdriver; Pipe Wrench; Two Adjustable Wrenches; 1/4 in. Nut Driver, Socket or Wrench;
240 Volt, 30 Amp Double Pole Circuit Breaker; Voltage Meter; Vibration Pads; 3/8 in. x 5 in. Wedge
Anchors (for concrete installation)
